No Barrier or Isolator Needed No Intrinsic Safety Ground Required Class I Div 1 Groups C, D Listed AEx Zone 1 Certified Zone 1 & 2 Certified Fits Shafts Up to 2" [52mm] Fully Protected Against Shorts and Wiring Errors Up 100000 PPR Fully Potted Electronics Wide Sensor-Rotor Gap: No Shimming 2 Year No-Hassle Warranty

Click to view the XP5 Series Datasheet in *.pdf format

XP5 SMARTSafe™ sensors power the world's first explosion-proof encoder with removable electronics and no external barrier! They are cULus, ATEX, AEx & IECEx certified and offer incredibly reliable no-bearing construction! SMARTSafe XP5 sensors can be used in ATEX/IECEx, cUL, AEX, and UL gas hazardous environments. Also available: no-bearing modular encoders (XPH8), as well as intrinsically safe models (XR5, XR12, XR56, XR125, XR485, XR685, XR850), and hollow shaft models (M6C).

For Level 1 applications requiring ATEX/IECEx Zone 1 or cULus Class I, Division 1, Groups C & D use the XP5 directly in your application with no barrier or isolator required.

Unlike the competition, Avtron SMARTSafe encoder systems are protected against short circuits, power-to-output wiring, and output-to-ground faults. XP5 features full diagnostics: it's easy to determine that signal quality is good, and that there are no wiring short-circuits.

Instead of mounting a tiny optical encoder with weak bearings on a wobbling stub shaft mount XP5 directly on your machine and install the rotor on your main application shaft. Top drives, draw works, coil tubing, paint lines...so many applications benefit from a more reliable no-bearing encoder. Vibration, shock, liquids, dust and dirt won't harm SMARTSafe XP5 encoders!

Eliminate the biggest cause of hazardous duty encoder failure--eliminate the bearings with XP5 hazardous duty encoder sensors.

Specs:
Operating Power: Volts: 5-24VDC in/out; Current: 400mA max @ 5V; 200mA max @ 12V; 100mA max @ 24V (plus cable load)
