The STM17C-3CN integrated stepper is designed to operate on a CANopen communication network and conforms to Can in Automation (CiA) DS301 and DSP402 specifications. It supports Profile Position, Profile Velocity, and Homing modes, as well as the ability to run stored Q programs via Applied Motion-specific CANopen objects. All STM17 units are setup and configured using Applied Motion’s ST Configurator™ software.

Each STM17 integrated stepper comes with 3 digital inputs, 1 digital output, and 1 analog input. The digital inputs accept signals of 5-24 VDC and can be used for connecting pulse & direction signals, end-of-travel limit switches, jog switches, quadrature encoder signals, PLC outputs, sensors, or many other signal types. The digital output can be connected to PLC inputs, counters, lights, relays, or other devices. The analog input accepts 0-5 VDC signals and can be used for velocity and position control.

The STM17C-3CN comes with an RS-232 port for programming and a CANopen port for network communications.

• Sophisticated current control
• Anti-resonance
• Torque ripple smoothing
• Microstep emulation
• NEMA 17 frame size
• DS301 and DSP402 supported
• Profile position, velocity and homing modes
• Objects for Q programming
• Objects for data registers
• RS-232 port for programming

Download the STM17C-3CN specification sheet in *.pdf format
