Overview

• Offered in retroreflective models with two discrete outputs (PNP) for extremely long ranges up to 250 m
• Available in diffuse models with two discrete outputs (PNP) and one 4-20 mA output for long-range background suppression up to 10 m
• Provides two alarm outputs with ongoing LCD display for easy troubleshooting
• Features TEACH-mode programming, using integrated push buttons or serial interface
• Continually displays sensing distance in millimeters or hundredths of an inch
• Delivers excellent ±10 mm linearity
• Offers choice of RS-422 or SSI-compatible serial connection
• Uses visible Class 2 alignment laser for accurate alignment
• Provides quick warmup to minimize drift

Click to view the SMBLT7F specification sheet in *.pdf format
