The Q5X background suppression laser is a powerful, problem-solving sensor in a cost-effective device with industry-standard rectangular housing. The best-in-class laser triangulation sensor features a range from 9.5 cm (4 inches) to 2 m (6 ft. 6 inches), is easy to use, and provides reliable detection of the most challenging targets.
High excess gain for reliable detection of the darkest objects (<6% reflective black targets)
Reliable detection of black targets against a black background, black targets against a shiny metal background, clear and reflective objects, multicolor packaging, and targets of all colors
Bright output indicator and real-time distance feedback enable simple setup and troubleshooting
Dual teach mode measures both distance plus light intensity to solve the most challenging applications
Intuitive user interface with the same buttons, setup, and display as other Banner laser products
270-degree rotatable M12 QD to meet a variety of mounting constraints
Rated IP67 for reliable performance in wet environments
Programmable via on-board user interface, remote teach, IO-LInk or optional remote sensor display
Remote Sensor Display (RSD) enables remote programming and monitoring
Applications
The Q5X laser sensor solves a wide variety of challenging applications in food and beverage, packaging, material handling, and automotive industries. Ideal applications include:
- Part in place inspections
- Part motion complete
- Detection of black plastic, leather, and rubber parts
- End of line pallet detection
- Shrink wrap detection
- Carton full /empty
- Box, tote, and pallet detection
- Detection of construction materials (timber, plywood, sheetrock, steel, asphalt, etc.)ยท
|
