Sensing Mode (General)ProximitySensing Mode (Detailed)TriangulationHousing StyleRectangularPrimary Housing MaterialStainless SteelLaser ClassificationClass 2Input/OutputAnalog & DiscreteIndicatorLED(s)Analog Output Configuration4-20 mAAnalog Resolution/Discrete Repeatability0.004 mmMax Sensing Distance (mm)150Minimum Sensing Distance (mm)50Sensing BeamVisible Red LaserPower Supply10-30 V dcDelay at Power-up (ms)2100Sensing Beam Wavelength (nm)655AdjustmentsRemote TeachTemperature Effect (mm/°C)+/- 0.008 mm/°CConnectionPigtail QDQD Type/Cable LengthM12 (Euro) requires mating cordsetNumber of Pins5VibrationIEC 60947-5-2 (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).Mechanical ShockIEC 60947-5-2 requirements: 30G 11 ms duration, half sine waveOutput Saturation Voltage NPN Outputs< 2.5 V at 50 mAOutput Saturation Voltage PNP Outputs< 3 V at 50 mAAnalog Current Output Rating500 Ω maxMax Discrete (Switched) Output (mA)50Discrete (Switched) Outputs1 NPN/PNP ConfigurableOutput ProtectionProtected against continuous overload and short circuitIP RatingIP67Storage Temperature (°C)-35 to 60Max Operating Temperature (°C)55Min Operating Temperature (°C)-10Max Op. Relative Humidity Non-Condensing (%)90 at 55°CWindow MaterialAcrylicWarm-up Time (minutes)10Minimum Response Time (ms)0.5Spot Size (@ Reference Distance)0.77 mm x 0.31 mm @ 150 mmAnalog Linearity (mm)50 mm to 120 mm: ± 0.060 mm, 120 mm to 150 mm: ± 0.070 mmMinimum Window Size (mm)0.1Discrete Output Hysteresis (mm)Automatically adjustedLaser ControlYesAlarm Output (mA)50Max Ambient Light (Lux)10000Power/Current Consumption (exclusive of load)< 62 mA at 24 V dcSupply Protection CircuitryProtected against reverse polarity and transient overvoltagesFeature: Remote TeachYesFeature: Clear Object DetectionYesFeature: Timing (Hold/Delay)YesFeature: Chemical ResistantYesFeature: Pump-in/ Pump-outNoFeature: Health/ Marginal Signal OutputYesIO LinkYesRS-232NoRS-422NoRS-485NoSSINoWirelessNo1-wire Serial InterfaceNoProfibusNo
