Overview

• Increases the switching current capacity of low voltage primary safety devices to 6 amps
• Serves as a relay for primary safety devices with OSSD solid-state or hard contact outputs and external device monitoring, such as the EZ-SCREEN
• Offers 24V dc supply voltage
• Available with two or three normally open (NO) safety outputs, depending on model
• Features model with one normally closed (NC) non-safety auxiliary output
• Includes removable terminal blocks
• Responds in 20 milliseconds
• Uses two green LEDs to indicate the output status of internal relays K1 and K2
• Rated IEC IP20; NEMA 1

Click to view the IM-T-9A specification sheet in *.pdf format
