PS9Z-6RM4 - IDEC DC-DC Converter +-15V0.4A

PS9Z-6RM4 - IDEC
PS9Z-6RM4

Price: $54.04
Manufacturer SKU: PS9Z-6RM4


Free Shipping
Availability: Usually Ships in 3 to 5 Business Days
Part Number: PS9Z-6RM4
Qty:

Description Technical Specs

PS9Z-6RM4 - IDEC DC-DC Converter +-15V0.4A
DC-DC Converter +15V, 0.4A/-15V, 0.4A, 12W

The PS6R Series Family
Meet the PS6R series. They're the first DIN rail-mounted industrial power supplies that expand to provide multiple output voltages from a single unit. These compact units pack big performance into remarkably small spaces. Add a 10W DC-DC converter unit or add two branch terminals -without sacrificing efficiency or performance.

Multiple Voltage Output
Additional DC-DC converter units can be added to give you up to three separate output voltages - 5V, 12, and 15V

Add Wiring Terminals
Run out of terminal slots? No problem! Simply add a branch terminal module to get two additional + and - slots.
  • Energy-saving 93% Efficiency
  • Easy Maintenance - LED Indicator
  • Finger-safe prevents electric shocks
Key Features
  • 93% efficiency
  • Plug-in output modules for additional output voltages
  • Plug-in branch terminal module for additional terminals
  • Power Range: 120W, 240W, 480W
  • Input voltage: 100 to 240V AC (voltage range:85 to 264V AC/110 to 350V DC)
  • Up to 70C/158F operating temperature
  • DC low LED indicator and output contact
  • The terminals are captive spring-up screws. Ring or fork terminals can be used.
  • Finger-safe construction prevents electric shocks.
  • Panel mount bracket and side-mount panel mounting bracket. Can be attached to a DIN rail or directly to a panel surface.
  • RoHS compliant
pdfDownload the PS6R Series Power Supplies product brochure in *.pdf format
