Highest Precision High Wear Resistance Suited for High Cycle Rate/ Short Move Application. Rotary Flange, Round, Thru Hole Flange, Machine Mounting

• Output torque

  • T2N : Up to 10,900 Nm

  Frame Sizes (mm)

  • 64/90/110/140/200/255/285/355/450

  Ratios

  • 1-stage : 4 / 5 / 7 / 10
  • 2-stage : 16/20/21/25/28/31/35/40/46/50/61/70/91/100

  Lowest Backlash - High Wear Resistance

  • 1-stage : ≤1 arcmin
  • 2-stage : ≤1 arcmin

  High Efficiency

  • 1-stage : ≧ 97%
  • 2-stage : ≧ 94%

  Easy mount
  Low Noise
  Compact structure

Click to view the AH Series Documentation in *.pdf format

Click to view the AH Series Mounting Instructions in *.pdf format
