Highest Precision High Wear Resistance Alloy Steel Construction/ Hardened and ground Gearing. Rotary shaft, Square, thru hole flange, machine mounting.

• Output torque
  T2N : 24 Nm - 4090 Nm
• Ratios
  1-stage : 3 / 4 / 5 / 6 / 7 / 10
  2-stage : 16 / 20 / 25 / 28 / 35 / 40 / 50 / 70 / 100
  60 / 70 / 80 / 90 / 100
• Low backlash
  1-stage : ≤1arcmin
  2-stage : ≤2arcmin
• High efficiency
  1-stage : ≧ 97%
  2-stage : ≧ 94%
• Easy mount
• Low Noise
• Compact structure

Click to view the AFH Series Documentation in *.pdf format
