MO325-16 - ABB MO325-16, 3PH MAN STARTER 12.5-16A MAG ONLY

MO325-16 - ABB
MO325-16

Price: $214.03
Returnable: NOT RETURNABLE
Manufacturer SKU: MO325-16
Manufacturer ID: 804325496254


Free Shipping
Availability: Usually Ships in 3 to 5 Days
Part Number: MO325-16
Qty:

Description

MO325-16 - ABB MO325-16, 3PH MAN STARTER 12.5-16A MAG ONLY

A complete motor protection concept

Manual motor starters (MMS) are protection devices for the main circuit. They combine motor control and protection in a single device. MMS are used mainly to switch motors manually ON/OFF and protect them and the installation fuse less against short-circuit, overload and phase failures. Fuse less protection with a manual motor starter saves costs, space and ensures a quick reaction under short-circuit condition, y
switching off the motor within milliseconds.

MS116 is a compact and economic range for motor protection up to 15.5 kW (400 V) / 32 A in width of 45 mm. Further features are the build-in disconnect function, temperature compensation, trip-free mechanism and a rotary handle with a clear switch position indication. The manual motor starter is suitable for three- and single-phase applications. Auxiliary contacts, signalling contacts, undervoltage releases, shunt trips, threephase bus bars, power in-feed blocks and locking devices for protection against unauthorized changes are available as accessory.

Main benefits

  • Compact design
  • Efficient planning and installation perfectly matching the ABB contactor family
  • Simple connecting links ensure electrical and mechanical connection to build direct-on-line starters
  • Less machine downtime by protecting motors and reduced trouble shooting
  • Reduction of maintenance expenditures by protecting motors
  • Comprehensive accessory range (busbars, auxiliary contacts, signaling contacts...).

Main features

  • Manual control / short-circuit current and overload protection
  • Adjustable current setting for overload protection and magnetic trip indication
  • Disconnection function
  • Temperature compensation
  • Remote control via undervoltage release or shunt trip
  • Short-circuit service breaking capacity Ics up to 100 kA.
pdfDownload the Motor Protection and Control brochure in *.pdf format
